Mercury MPM 1.5K RT Online UPS – Rackmount & Tower Convertible (UK Plug)

1.5KVA / 1.35KW | True Online Double Conversion | 0.9 Power Factor | RS232 & USB Interface

Key Highlights:

• Capacity: 1500VA / 1350W (0.9 Power Factor)

• Topology: True Online Double Conversion UPS – Provides pure sine wave output for critical and sensitive equipment

• Convertible Design: Rackmount & Tower Convertible for flexible deployment

• Input/Output Phase: Single-phase input, single-phase output (1/1)

Battery System:

• DC Voltage: 36VDC

• Battery Configuration: 3 x 12V / 9Ah Sealed Lead Acid Batteries

• Hot-swappable battery support (optional depending on model)

• Backup Time: 10–30 minutes (load-dependent)

• Recharge Time: Approx. 4–6 hours to 90% capacity

Power Connections:

• Input Plug: UK 3-pin

• Output Sockets: 2 x Universal AC Outlets

• Bypass Mode: Supports Automatic and Manual Bypass

Communication & Monitoring:

• RS232 & USB Ports – For monitoring and auto shutdown

• Smart Software Support: Real-time monitoring, event logging, remote management

• Optional SNMP Card Slot – For network-based power monitoring

Technical Specifications:

• Input Voltage Range: 110 – 300VAC

• Frequency: 50/60Hz (auto-sensing)

• Output Voltage: 208/220/230/240VAC ± 1%

• Waveform: Pure Sine Wave

• Transfer Time: 0 ms (always online – no switching delay)

Protection & Reliability:

• Overload & short circuit protection

• Input surge/spike suppression

• Over-temperature protection

• Battery overcharge & deep discharge protection

• Cold start and automatic restart features

Ideal For:

• Servers and data centers

• Networking and telecom equipment

• Medical equipment

• Industrial control systems

• High-end workstations and sensitive electronics

Physical & Design:

• Form Factor: Convertible (rackmount kit and vertical stand included)

• Display: LCD screen for real-time system status

• Cooling: Intelligent fan control based on load & temperature
